G209 Early Strength Additive for Oil Well Cementing

Appearance Fineness (0.315mm sieve),%
Free flowing powder ≤15.0
Thickening time ratio/32℃,8.3MPa,17min Initial consistency, Bc/32℃,8.3MPa,17min
≤0.5 ≤30.0
    Contact us Download
    product details

    description1

    Product Description

    G209 can change ion concentration in cement hydrate to accelerate the acting of C3S、C3A and forming of calcium aluminous stone. So it can densify the structure and enhance early strength.

    Characteristics

    G209 main consists of inorganic compound.
    Normal dosage: 1.5%~4.0% (BWOC).
    Suitable temperature: 28℃~110℃(BHCT).
    Suitable for low and conditional density cement slurry .
    Suitable for low density cement slurry of fly ash ,normal oil well cement and low density cement slurry of glass micro-spheres.
    Preferred to mix with water.

    Technical Specification

    The ingredient of cement slurry in the table is: JiaHua G class cement, W/C: 0.44,
    G209 :2.0%(BWOC), Water quality: distilled water.

    Items

    Specification

    Appearance

    Free flowing powder

    Fineness (0.315mm sieve),%

    ≤15.0

    Thickening time ratio/32℃,8.3MPa,17min

    ≤0.5

    Initial consistency, Bc/32℃,8.3MPa,17min

    ≤30.0

    Compression strength, MPa/39℃,normal pressure,6h

    ≥4.0

    Compression strength ratio, MPa/39℃,normal pressure,24h

    ≥1.0

    Note 1: The thickening time ratio refers to the thickening time of cement slurry with early strength agent and the thickening time of pure cement slurry.

    Note 2: Compression strength ratio refers to the compression strength of cement with early strength agent and the ratio of compression strength of pure cement slurry.

    Note 3: Content in brackets is test conditions.

    Packing, Storage

    Be sacked with three-layer plastics bag, 25kg per bag.
    Be kept away from moisture, Stored in cool and dry situation.
    Storage life time is two years.
